CMM-Manager DCC Standard is available for motorized / CNC CMMs. 3D CAD import is included with this software version. CAD formats include IGES, Step, DXF, and several XYZ point formats. 3D CAD data is used to automatically generate collision-free measurement paths with all supported probing systems. This CAD enabled version allows user to create visually compelling graphical reports.
- For use on Motorized CMM.
- 2D / 3D CAD Import, including IGES, STEP, DXF.
- Plug-n-Play – No Hardware Retrofit Required.
- Create Programs with Manual and DCC Features.
- Automatic Probe Calibration.
- Teach DCC Features by CAD Pick, Joystick Teach or Key-In Values.
- Automatic / Collision Free, Clearance Plane or Local Path Planning.
- Share Programs with Manual or Portable Equipment.
- Export Measured Features, Point Clouds & Curves as CAD.
- Open and Run Legacy DMIS Programs.
Plug-n-Play to Existing Equipment
- Sheffield – SMP / MP
- Brown & Sharpe – Sharpe2 / 32
- DEA – Tutor
- Hexagon – RC1 / DC / Leitz
- Mitutoyo – CMMC / UC200-400
- Zeiss – C90 / C99
- Renishaw – UCC – I++
- zCat – Portable DCC CMM
- Haas – HMM430
- Helmel – PMAC
- Wenzel
- LK / Nikon
- Starrett – API
- Deva
- Pantec WPC
- Tarus CMM
- Fowler – Fusion Mark 4
Software Highlights
Clean UI:
CMM-Manager’s unique user interface gives you clutter-free access to commonly used tools. When you’re ready for more functionality, the advanced tools you need are available with the click of a button.
Measure from CAD:
Pick features from CAD to create collision free measurement paths. CMM-Manager takes care of clearance motion and tip angle changes.
Virtual Simulation:
Display visual simulation of measurement paths for features or for the entire program. CMM-Manager will estimate the running time for the program.
Reporting:
Create reports using intuitive dimensioning and GD&T tools. Create graphical reports that display CAD, drawing, or actual part view with annotations for a visually compelling report document.
Save Reports:
Print, Save or View Reports in many built-in formats including PDF, Microsoft Excel, QC-Calc, CSV, & simple Text. Create or use your own report templates using DDE.
Alignment Tools:
Perform an alignment on simple shapes with our Traditional Alignment Toolbox or to complex shapes using Best-Fit, RPS, Iterative, and other powerful alignment tools.
Software Options
- Gear Inspection Module
- SP25 or Revo Scanning Probe
- Vision Probe
- Rotary Table / Indexer
- Native CAD Import
- QC-Calc SPC Software
