4th Axis and Rotary Table

CMM-Manager supports rotary table and 4th axis devices for manual and motorized CMMs:

• Simplify inspection of parts with multiple orientations.
• Enable rotational re-orientation of the part to reduce the need for manual fixturing or repositioning.
• Automate measurement of complex parts with features on multiple sides.

Benefits of Using Rotary Tables with CMM-Manager:

• Reduced fixturing complexity by allowing part reorientation instead of building multi-angle setups.
• Improved measurement efficiency for prismatic and rotational parts.
• Expanded inspection capability for features on multiple surfaces without removing and re-aligning the part manually.
• Supports inspection of gears, turbine components, and multi-sided parts.

Types of Supported Devices:

• Newmark NSC-A1
• Sheffield CMM (built-in)
• LK Metrology CMM (built-in)
• Renishaw UCC / I++
• Accu-Smart 55
• Manual Indexer – IMUSB
